737 Flight Crew Operations Manual
Flight Instruments, Displays -
Electronic Flight Bag (EFB)
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.65.7
1 Selectable Applications (Soft Keys)
Menu items for selectable applications display in white text with gray
background. Items may be selected using the Line Select Keys (Hard Keys) or
touch screen (Soft Keys).
2 Applications not selectable
Menu items for applications that are installed but are not selectable display in cyan
text in a cyan box. An application may be initializing and may become selectable
later.
3 Cursor
A magenta cursor appears on the display when the SIDE switch is selected on a
cursor control device.
4 High-light Box
A white high-light box displays around a selectable application when:
• The cursor is moved over the menu item
• The selectable menu item is touched
• The associated line select key is selected.
A selectable application is selected when:
• It is high-lighted with the cursor and the cursor select switch is pushed
• A menu item is touched and released
• The associated line select key is selected.
The menu item for a selected application displays a green background
momentarily and then the selection displays.
March 27, 2014
