737 Flight Crew Operations Manual
Flight Instruments, Displays -
Electronic Flight Bag (EFB)
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.65.13
1 Map Reference
Displays the map reference.
• TRK-UP (track up) and MAG (magnetic).
2 NORTH-UP MAP
Selects north up (static) map display.
3 Airport (APRT) SEARCH
Allows searching the database for other airport maps.
4 Airplane symbol
Displays when airplane is on the ground at the displayed airport and groundspeed
is less than 40 knots.
5 Display range
Indicates the map range from top to bottom of the display.
6 Airport Identifier
When departure airport is displayed, identifier is destination airport if entered in
FMC.
• Selection displays the destination airport in TRK-UP (moving map)
mode when on the ground at the destination airport
• Displays the destination airport in NORTH UP (static) mode when in
the air.
When destination airport is displayed, identifier is departure airport.
7 SHOW/HIDE Range (RNG) RING
Displays or removes a 300 meter radius range ring around the airplane symbol.
8 SHOW/HIDE MENU
Displays or hides all other menu selections.
September 15, 2016
