737 Flight Crew Operations Manual
Flight Instruments, Displays -
Electronic Flight Bag (EFB)
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.65.15
1 Map reference
Displays the map reference
• NORTH UP
• TRU (true) heading.
2 TRK-UP MAP
Selects track up moving map display.
3 Airplane Symbol
Displays when airplane is on the ground at the displayed airport and groundspeed
is less than 40 knots.
4 CANCEL/RECALL MSGS (Messages)
Toggles between Cancel and Recall when map faults exist
• CANCEL removes fault messages from the display
• RECALL re-displays fault messages.
The menu item is inhibited when there are no faults to display.
5 CENTER A/C
Centers airplane symbol horizontally and vertically on the display.
6 Map fault message display area
Amber fault messages display in this area. More than one message may display at
a time.
Faults may appear on both NORTH-UP and TRK-UP displays.
September 15, 2016
