737 Flight Crew Operations Manual
Flight Instruments, Displays -
Electronic Flight Bag (EFB)
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.65.37
1 LOCATION
Displays a list of airplane areas (Flight Deck, Engine, Exterior, etc.) for use in
locating an area where a fault has occurred.
2 FAULT NOT FOUND
Displays a blank fault report form for the user to complete. This is required when
a fault can not be found in the selected area.
3 SHOW/HIDE MENU
Toggle button to either show or hide the extended menu selections.
4 Panel Selection Area
Selection of line select keys within the brackets navigates through a series of
images to help identify a fault. The purpose is to narrow the search area to find the
appropriate fault code.
5 VIEW FAULTS
Displays a list of all faults associated with the region displayed. The more the
region is narrowed by selecting specific areas within a graphic, the fewer faults
are returned.
September 15, 2016
