737 Flight Crew Operations Manual
Flight Management, Navigation -
FMC Descent and Approach
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
11.43.18 D6-27370-866-EGP
1 STARS
Displays the selected STAR.
2 Arrival Transitions (TRANS)
Displays all arrival transitions related to the selected STAR.
3 Selected Status Label (<SEL>)
Identifies arrival/approach procedures or a runway which has been selected for
entry into the route, but not executed.
All <SEL> entries propagate to the MOD RTE and MOD RTE LEGS pages for
subsequent execution.
4 Approach and Runway (APPROACHES, RUNWAYS)
Displays all approaches related to the selected STAR, followed by all related
runways (unless the desired approach/runway was selected on the initial display).
5 Arrival Transition (TRANS)
Displays the selected arrival transition.
6 APPROACHES
Displays selected approach/runway.
7 Approach Transition (TRANS)
Displays all approach transitions related to the selected approach.
8 Active Status Labels (<ACT>)
Following execution of the selected entries, the arrival/approach procedures and
runway are identified as active.
Note: For an existing active route, the execute key illuminates upon STAR or
approach/runway selection. Following selections, the ERASE prompt is
available. Selections should be executed on the RTE or RTE LEGS pages
after linking any route discontinuities.
September 24, 2015
