737 Flight Crew Operations Manual
Performance Inflight
General
737-800WSFP1/CFM56-7B26
FAA
Category C/N Brakes
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
PI.10.48 D6-27370-866-EGP
Flight With Unreliable Airspeed/ Turbulent Air Penetration
Altitude and/or vertical speed indications may also be unreliable.
Holding (VREF40 + 70)
Flaps Up, %N1 for Level Flight
Terminal Area (5000 FT)
%N1 for Level Flight
Final Approach (1500 FT)
Gear Down, %N1 for 3° Glideslope
Go-Around
Flaps 15, Gear Up, Set Go-Around Thrust
PRESSURE ALTITUDE (FT)
WEIGHT (1000 KG)
40 50 60 70 80
15000
PITCH ATT 5.0 5.0 5.0 5.0 5.0
%N15662667073
KIAS 177 193 212 229 246
10000
PITCH ATT 5.0 5.0 5.0 5.0 5.0
%N15258626669
KIAS 177 192 211 228 244
5000
PITCH ATT 5.0 5.5 5.0 5.0 5.0
%N14954586266
KIAS 177 191 210 227 243
FLAP POSITION
(VREF + INCREMENT)
WEIGHT (1000 KG)
40 50 60 70 80
FLAPS UP (GEAR UP) PITCH ATT. 4.5 5.0 5.5 6.0 6.0
(VREF40 + 70) %N1 49 54 58 62 65
FLAPS 1 (GEAR UP) PITCH ATT. 4.5 5.0 5.5 6.0 6.0
(VREF40 + 50) %N1 51 56 60 64 68
FLAPS 5 (GEAR UP) PITCH ATT. 5.5 5.5 6.0 6.5 6.5
(VREF40 + 30) %N1 51 57 61 65 69
FLAPS 15 (GEAR DOWN) PITCH ATT. 5.0 5.5 5.5 6.0 6.0
(VREF40 + 20) %N1 58 63 68 73 76
FLAP POSITION
(VREF + INCREMENT)
WEIGHT (1000 KG)
40 50 60 70 80
FLAPS 15 PITCH ATT 2.0 2.0 2.0 2.5 2.5
(VREF15 + 10) %N1 40 44 48 51 54
FLAPS 30 PITCH ATT 0.5 1.0 1.0 1.0 1.0
(VREF30 + 10) %N1 47 52 56 60 63
FLAPS 40 PITCH ATT -0.5 -0.5 -0.5 0.0 0.0
(VREF40 + 10) %N1 52 58 62 66 70
PRESSURE ALTITUDE (FT)
WEIGHT (1000 KG)
40 50 60 70 80
10000
PITCH ATT 20.0 16.0 13.5 11.5 10.5
V/S (FT/MIN) 3900 3100 2500 2000 1600
KIAS 128 142 155 165 175
5000
PITCH ATT 24.0 19.0 16.0 14.0 12.0
V/S (FT/MIN) 4600 3700 3000 2500 2100
KIAS 128 142 154 164 175
SEA LEVEL
PITCH ATT 28.0 22.0 18.0 16.0 14.0
V/S (FT/MIN) 5200 4200 3500 2900 2500
KIAS 128 142 154 164 174
September 15, 2016
