737 Flight Crew Operations Manual
Performance Inflight
Advisory Information
737-800WSFP1/CFM56-7B26
FAA
Category C/N Brakes
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP PI.12.23
ADVISORY INFORMATION
Non-Normal Configuration Landing Distance
Trailing Edge Flap Asymmetry (Flap Lever 15 or 25)
VREF15
Dry Runway
Good Reported Braking Action
Medium Reported Braking Action
Poor Reported Braking Action
Reference distance is based on sea level, standard day, no wind or slope, and maximum available reverse
thrust.
MAX MANUAL assumes maximum achievable manual braking.
Reference Distance includes an air distance allowance of 305 m from threshold to touchdown.
Actual (unfactored) distances are shown.
*For landing distance at or below 8000 ft pressure altitude, apply the STD adjustment. For altitudes higher
than 8000 ft, first apply the STD adjustment to derive a new reference landing distance for 8000 ft then apply
the HIGH adjustment to this new reference distance.
LANDING DISTANCE AND ADJUSTMENTS (M)
REF
DIST
WT
ADJ
ALT
ADJ
WIND
ADJ
SLOPE
ADJ
TEMP
ADJ
APP
SPD
ADJ
REVERSE
THRUST
ADJ
BRAKING
CONFIGURATION
65000 KG
LANDING
WEIGHT
PER
5000 KG
ABV/BLW
65000 KG
PER
1000 FT
STD/HIGH*
PER
10 KTS
HEAD/
TAIL
WIND
PER 1%
DOWN/
UP
HILL
PER
10°C
ABV/
BLW
ISA
PER
5 KTS
ABOVE
VREF
ONE
REV
NO
REV
MAX MANUAL 970 75/-60 20/30 -35/120 10/-10 20/-20 35 20 45
AUTOBRAKE MAX 1270 70/-70 30/40 -45/155 0/0 30/-30 60 0 5
AUTOBRAKE 2 2270 150/-160 70/95 -105/350 35/-45 65/-65 90 105 105
MAX MANUAL 1320 75/-75 35/45 -55/200 30/-25 35/-35 45 70 160
AUTOBRAKE MAX 1420 80/-85 40/50 -60/210 30/-20 35/-35 55 80 175
AUTOBRAKE 2 2270 150/-160 70/95 -105/350 35/-45 65/-65 90 105 105
MAX MANUAL 1815 120/-120 55/75 -90/330 80/-65 50/-50 60 195 485
AUTOBRAKE MAX 1860 120/-125 60/80 -95/335 75/-60 50/-55 70 200 490
AUTOBRAKE 3 1990 125/-130 60/80 -95/350 55/-40 55/-60 100 125 390
MAX MANUAL 2375 170/-170 85/115 -140/525 195/-125 70/-75 75 425 1165
AUTOBRAKE MAX 2375 170/-170 85/115 -140/525 195/-125 70/-75 75 425 1160
AUTOBRAKE 3 2405 170/-170 85/115 -140/530 185/-115 70/-75 90 425 1165
September 15, 2016
