737 Flight Crew Operations Manual
Automatic Flight -
Controls and Indicators
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
4.10.22 D6-27370-866-EGP
3 Roll Armed Mode
4 Pitch Engaged Mode
5 Mode Highlight Change Symbol
YK981 - YQ456
A mode change highlight symbol (rectangle) is drawn around each pitch, roll,
CWS, A/P status, and thrust engaged mode annunciation for a period of 10
seconds after each engagement.
YW273, YW274
A mode change highlight symbol (rectangle) is drawn around each pitch, roll, A/P
status, and thrust engaged mode annunciation for a period of 10 seconds after each
engagement. The mode highlight change symbol for CWS Mode annunciations
(CWS R and CWS P) will flash for 10 seconds when CWS mode engages.
6 CWS Roll Engaged
7 Autopilot Status
8 CWS Pitch Engaged
9 Pitch Armed Mode
• VOR/LOC (white)
• LNAV VOR/LOC (white)
• LNAV (white)
• TO/GA (green)
• V/S (green)
• MCP SPD (green)
• ALT/ACQ (green)
• ALT HOLD (green)
• G/S (green)
• FLARE (green)
• VNAV SPD (green)
• VNAV PTH (green)
• VNAV ALT (green)
• CWS R (amber)
• CMD (green)
• SINGLE CH (amber)
• FD (green)
• CWS P (amber)
• G/S (white)
• V/S (white)
• VNAV (white)
• FLARE (white)
• G/S V/S (white)
