737 Flight Crew Operations Manual
Flight Controls -
Controls and Indicators
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
9.10.6 D6-27370-866-EGP
4 Stabilizer Trim Switches (spring-loaded to neutral)
Push (both) –
• electrically commands stabilizer trim in desired direction
• autopilot disengages if engaged.
5 Stabilizer Trim Main Electric (MAIN ELECT) Cutout Switch
NORMAL – normal operating position.
CUTOUT – deactivates stabilizer trim switch operation.
6 Stabilizer Trim AUTOPILOT Cutout Switch
NORMAL – normal operating position.
CUTOUT –
• deactivates autopilot stabilizer trim operation
• autopilot disengages if engaged.
7 Stabilizer Trim Override Switch
OVERRIDE – bypasses the control column actuated stabilizer trim cutout
switches to restore power to the Stabilizer Trim Switches
NORM (guarded position) – normal operating position.
8 Stabilizer Out of Trim (STAB OUT OF TRIM) Light
Refer to Chapter 4 – Automatic Flight
September 28, 2006
