737 Flight Crew Operations Manual
Flight Controls -
Controls and Indicators
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
9.10.8 D6-27370-866-EGP
2 Rudder Trim Indicator
Indicates units of rudder trim.
3 Rudder Trim OFF Flag
Illuminated (amber) (in view) – rudder trim indicator is inoperative.
4 Rudder Trim Control (spring-loaded to neutral)
Rotate – electrically trims the rudder in the desired direction.
YK981 - YK992
5 YAW DAMPER Indicator
• Indicates main yaw damper movement of rudder
• pilot rudder pedal inputs are not indicated.
September 23, 2010
