737 Flight Crew Operations Manual
Flight Controls -
Controls and Indicators
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
9.10.16 D6-27370-866-EGP
4 Elevator (ELEV) (white)
Indicates elevator position:
• top mark depicts maximum up position
• center mark depicts neutral position when on the ground and trimmed in
the green band
• bottom mark depicts maximum down position.
Note: Elevator neutral position varies with stabilizer position, flap position and
Mach. The center index mark is set for nominal takeoff conditions. With
certain airplane nose up trim settings, the pointer will be somewhat
displaced.
5 RUDDER (white)
Indicates rudder position:
• left mark depicts maximum left position
• center mark depicts neutral position
• right mark depicts maximum right position.
Note: Main and standby yaw damper movement of the rudder are shown on this
indicator.
