737 Flight Crew Operations Manual
Flight Instruments, Displays -
PFD/ND – Displays
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
10.11.12 D6-27370-866-EGP
2 Pitch Limit Indication (amber)
Indicates pitch limit (stick shaker activation for existing flight conditions).
• displayed when the flaps are not up.
• displayed at slow speeds with the flaps up.
3 Flight Director Bar (magenta)
Indicates flight director steering commands. (Refer to Chapter 4, Automatic
Flight).
4 Horizon Line and Pitch Scale (white)
Indicates the horizon relative to the airplane symbol; pitch scale is in 2.5 degree
increments.
Horizon scale is in 5 degree increments.
5 Bank Pointer
Indicates bank angle; fills and turns amber if bank angle is 35 degrees or more.
• indicates direction towards wings level.
6 Slip/Skid Indication
Displaces beneath the bank pointer to indicate slip or skid:
• fills white at full scale deflection
• turns amber if bank angle is 35 degrees or more; fills amber if the
slip/skid indication is also at full scale deflection.
7 Airplane Symbol
Indicates airplane attitude relative to the horizon.
8 Flight Path Vector (FPV) Indication (white)
Displays flight path angle and drift when selected on the EFIS control panel:
• flight path angle is displayed relative to the horizon line
• drift angle is displayed relative to display center.
September 15, 2016
