737 Flight Crew Operations Manual
Flight Instruments, Displays -
PFD/ND – Displays
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
10.11.22 D6-27370-866-EGP
3 Minimums Reference/Altitude (green)
Displays approach minimum reference and altitude set by the MINS selector on
the EFIS control panel:
BARO –
• displayed when selector is set to BARO, minimums are in feet MSL
• turns amber and flashes for 3 seconds when airplane descends below
selected minimum altitude
• changes back to green:
• when passing the selected minimum altitude plus 75 feet during go–
around
• at touchdown
• after pressing the RST switch on the EFIS control panel.
RADIO –
• displayed when selector is set to RADIO, minimums are in feet AGL
• blank when an altitude less than 0 feet is selected
• turns amber and flashes for 3 seconds when airplane descends below
selected minimum altitude
• changes back to green:
• when passing the selected minimum altitude plus 75 feet during go–
around
• at touchdown
• after pressing the RST switch on the EFIS control panel.
4 Landing Altitude Reference Bar
Indicates height above touchdown:
• White bar – 500 to 1000 feet above landing altitude
• Amber bar – 0 to 500 feet above landing altitude.
