737 Flight Crew Operations Manual
Flight Instruments, Displays -
PFD/ND – Displays
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.11.35
2 Bank Pointer (amber)
With ROLL/YAW ASYMMETRY or ROLL AUTHORITY alert active:
• bank pointer outline will turn amber.
With ROLL AUTHORITY alert active:
• bank pointer will fill amber if bank angle exceeds 15 degrees.
3 Slip/Skid Indication (amber)
With ROLL/YAW ASYMMETRY or ROLL AUTHORITY alert active:
• slip/skid indication outline will turn amber.
• slip/skid indication will fill amber if deflected greater than 25% of its
width,
4 Bank Pointer (red)
When roll command arrow shown:
• bank pointer fills red.
5 Slip/Skid Indication (red)
When roll command arrow shown:
• slip/skid indication outline will turn red.
• slip/skid indication will fill red if it is deflected greater than 25% of its
width.
6 Roll Command Arrow (red)
The roll command arrow points in the shortest direction to wings level. If the bank
angle passes 180 degrees, the roll command arrow points in the new shortest
direction to wings level. The roll command arrow is displayed with or without the
autopilot engaged.
The roll command arrow is shown when bank angle exceeds:
• 45 degrees if the pitch attitude is 25 degrees or less.
• 65 degrees if the pitch attitude is greater than 25 degrees.
The roll command arrow is removed:
• when the bank angle is less than 35 degrees for 2 seconds, or;
• immediately if the bank angle is less than 10 degrees.
September 15, 2016
