737 Flight Crew Operations Manual
Flight Instruments, Displays -
PFD/ND – Displays
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.11.37
1 Groundspeed/True Airspeed
2 Heading Pointer
3 Weather Radar Returns
4 Track Line and Range Scale
5 Map Options
6 Airplane Symbol
7 Map Source Annunciation
8 Wind Direction/Speed/Arrow
9 Current Track
10 Number 1 VOR/ADF Pointer
11 Weather Radar Annunciations
12 Active Waypoint/ETA/Distance–To–Go
13 Compass Rose
14 Selected Heading Bug
15 Active LNAV Route
16 Vertical Deviation Scale and Pointer
17 Position Trend Vector
18 Magnetic/True Reference
19 Number 2 VOR/ADF Pointer
20 VOR/ADF Selection, Ident/Frequency, VOR DME
September 15, 2016
