737 Flight Crew Operations Manual
Flight Instruments, Displays -
PFD/ND – Navigation Displays
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.41.19
SYMBOL NAME MODE REMARKS
Terrain status
annunciations
(A)
All Look-ahead terrain alerting
and display unavailable due
to position uncertainty.
Terrain status
annunciations
(A)
All GPWS terrain inhibit switch
in TERR INHIBIT position.
Terrain range
status
annunciations
(A)
MAP,
MAP CTR,
VOR,
APP
Terrain output range
disagrees with selected EFIS
control panel range.
Terrain range
status
annunciations
(A)
MAP,
MAP CTR
Terrain output range and map
display output range disagree
with selected EFIS control
panel range.
TERR POS
TERR INHIBIT
TERR RANGE
DISAGREE
MAP/TERR
RANGE
DISAGREE
March 27, 2014
