Using Athena
154
CAEAthena
PN: 905K520652 v2.8
Cardiovascular Features
Athena produces realistic heart sounds and a wide range of pathophysiologic conditions
synchronized to the QRS complex of the ECG and audible with a standard stethoscope.
Cardiovascular features are controlled from the Cardiovascular view in Müse. To access the
Cardiovascular view, from the Run screen, click the heart on the human form. The basic
Cardiovascular parameters appear. To view additional parameters, click the Basic/Additional switch.
The Cardiovascular View
Cardiovascular Features
Anatomy, Physiol-
ogy and Clinical
Signs
Description Software Control Manual Control
3- or 4-Lead ECG ECG waveforms can
be viewed on a
standard monitor
and/or on the
Patient Status Dis-
play. Normal and
abnormal cardiac
rhythms are linked
to patient
physiology (e.g.
blood pressure,
cardiac output).
None required;
specific rhythms can
be selected.
VIEW:
Cardiovascular
PARAMETER(S):
Cardiac Rhythm
ECG monitor may be
used.
The Basic/Additional
switch
