Cautions and Warnings
This device complies with part 15 of the FCC Rules and with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
1. This device may not cause interference
2. This device must accept any interference, including interference that may cause
undesired operation of the device
Cet appareil est conforme aux normes d’Industrie Canada exempts de licence RSS (s). Son
fonctionnement est soumis aux deux conditions suivantes:
1. Cet appareil ne doit pas provoquer d’interférences
2. Cet appareil doit accepter toute interférence, y compris les interférences pouvant
provoquer un fonctionnement indésirable de l’appareil
Any modifications made to this device without the express approval of CAE could void the user’s
authority to operate this equipment.
What’s Included
The WVL package includes the following items:
• Wireless Voice Link Handset (1)
• Olympus ME52W Standalone Microphone (1)
• AAA Alkaline Batteries (2)
• Quick Start Guide (1)
How Wireless Voice Link Works
The WVL is a radio pair that operates in the 2.4 GHz unlicensed radio band. The handset
communicates wirelessly with the base station located inside the simulator. The base station
converts the digitized microphone stream from the handset and outputs it via the base station to the
headphone and line out jacks. The output projects through the head speakers inside the simulator.
To accommodate multiple WVL pairs in close proximity, each WVL is assigned two RF channels on
which to operate. The RF channels divide up the 2.400 – 2.4835 GHz spectrum in 80 single
frequencies to prevent the WVLs from interfering with each other.
Due to the nature of the unlicensed 2.4 GHz band, there may be other devices such as Wi-Fi,
microwave ovens or Bluetooth® radios operating in the 2.4 GHz band as well. Therefore, two
channels are used to transmit the audio stream redundantly to avoid interference. In case there is an
interference in one channel, the other can be used to extract the audio stream.
To operate correctly, both the handset and base station should be set to the same frequency using
the DIP switches located in the devices. If the interference is too high, the WVL firmware has the
ability to change channels automatically to avoid interruption. This process occurs simultaneously in
both the handset and the base station without the need for user intervention. The units revert back
to the original frequency set on the DIP switches when both devices are restarted using the power
switch.
