Using the TouchPro Patient Monitor
114
CAEAthena
PN: 905K520652 v2.8
Modifying the TouchPro Patient Monitor
Display
The layout of the waveforms and numeric data shown on the software can be customized. The
software can show up to six waveforms plus an additional four numeric readouts.
Selecting a Preconfigured Layout
There are five preconfigured CAE Layouts:
• ICU-Arterial Line Only - preconfigured with waveform and numeric readouts for ECG
Lead II, ECG Lead V, ABP, Pleth, and a numeric readout for Body Temperature
• EMS-ED-Telemetry - preconfigured with a waveform and numeric readout for ECG Lead
II and numeric readouts for SpO
2
, and NIBP (noninvasive blood pressure)
• ICU-OR No CVP - preconfigured with waveform and numeric readouts for ECG Lead II,
ECG Lead V, ABP, PAP and Pleth, and numeric readouts for NIBP, Blood Temperature,
and Body Temperature
• ICU-OR - preconfigured with waveform and numeric readouts for ECG Lead II, ECG Lead
V, ABP, PAP, CVP and Pleth, and numeric readouts for NIBP, Blood Temperature, and
Body Temperature
• Saturation-Pulse - preconfigured with numeric readouts for SpO
2
and pulse
