• Chery QQ Service Manual Transmission System
Caution:
Do not distort the left side case.
3． Remove the 5th shift fork bolt and guide ball.
4． Hammer the slotted spring pin out.
Notice: It is much easier to magnetize the guide ball.
5．Remove the 5th shift fork, hub sleeve, synchronizer ring and 5th gear with
professional tools。
Caution:
Be sure not to press the synchronizer ring spring tightly.
1, Guide ball
2,
5
th shift fork bolt
3,Slotted spring pin
54
Chery Automobile Co., Ltd
