Chery QQ Service Manual
Starter technical data
Voltage 12V
Output power 0.8 KW
Start time 30 s
Rotation direction See from pinion side clockwise
Brush length 19 ㎜（0.650in）
Number of teeth of start pinion 9
Characteristic Condition Ensure
Empty load 11V Below 55A，above 5000 r/m
Load
9.5V
0.7Kg·m
Below 270A，above 1200 r/m
Temperature
20℃（68℉）
Braking 7.7V
Below 600A，above 1.3kg·m
（94 pound/feet）
Magnet switch working voltage Above 8V
- 13 -
