Section 3 Removal and installation of entire vehicle
lighting assembly
Explanation of lighting system
Chery S11series passenger car entire vehicle lighting fitting includes illumination
equipment and light signal equipment. It is used to guarantee the car’s normal running
and safe driving at night or in the fog. It includes: headlight (lower beam and upper
beam), front turning light (including small lamp), front foglight, combination taillight
(including backup lamp, turning light, braking/parking light, small lamp and so on),
license plate lamp, interior ceiling light, luggage compartment lamp and rear foglight.
Headlight apply half enclosed type lighting structure, it is convenient to examine and
repair; use halogen bulb to reduce bulb black and increase illuminating intensity and
extend the useful life of bulb.
Removal and installation of entire vehicle lighting assembly
1. Notice proceeding before removal:
a. Close control switch of corresponding lighting fitting, remove the wire connected to
battery;
b. Please don’t touch the bulb by your hands when replace the bulb, otherwise the
fingerprint on the bulb will be heated and volatilize after light up the bulb, and then it
will deposit on the lens surface, so the reflector will become dim.
2. Removal and installation of headlight
Please calibrate the headlight after remove and
install the headlight every time.
Removal:
——Open the engine compartment hood;
——Pull out the harness plug ;
——Remove front bumper（see front bumper removal）;
——Loose three bolts (M6*10) fixed on the headlight cross member;
——remove headlight.
