CHERY SQR7080 EZ Drive SERVICE MANUAL
MECHANICAL TRANSMISSION – RELAY
Position:
There are two relays that can be activated by the system:
n Start-up relay (A) near the buzzer under the instrument board (B).
n Pump relay on the interconnection box within the engine compartment.
Removal and Installation
Before maintaining the system, you shall turn off the engine and cut off the battery.
