Chery QQ - Table of Main Fitting Torque for SQR472 Enginesqr472

Chery QQ Service Manual Mechanical Part of SQR 472Engine
53
Chapter 5. Table of Main Fitting Torque for SQR472 EngineSQR472
No. Name Specification Quantity
Fixing Torque (Nm) Remark
1 Main bearing cap bolt M10X1.25 10 70±3.5
2 Connecting rod cover bolt M8X1 8 40±2
3 Oil pump bolt M8X1 6 20±1.5
4
Nut (oil collector
– oil ppump) M6 2 6±1
5 Bolt (oil collector – cylinder body) M6 1 6±1
6 Water pump bolt M8X1 6 25±1.5
7 Rear oil seal bracket bolt M8 5 25±1.5
8 Drain plug M12 1 45±3
9 Oil pan bolt M6 19 6±1
10
Bolt connecting exhaust camshaft with flange
(hexagonal)
M6 4 6±1
11 Exhaust camshaft locking nut M40X1.5(L) 1 100±5
12 Cylinder head bolt M10X1.25 10 70±3.5
13 Camshaft bearing cap bolt M6 19 9±1
14 Cylinder head chamber cover bolt M6 8 4.5±0.5
15 Camshaft position sensor bolt M8 1 10±1
16 Bolt (knock sensor) M8 1 20±1.5
17 Camshaft timing gear bolt M12X1.25 1 100±5
18 Tension pulley bolt M10 1 25±3
19 Timing cover bolt M6 7 6±1
20 Engine oil gauge pipe bolt M6 6±1
21 Flywheel assembly bolt M10X1.25 6 70±3.5
22 Thermoregulator shell bolt M8 2 10±1
23 Oil filter conncetor 3/4"-16 40±2.5
24 Oil filter
3/4"-16
20±1.5
