Chery QQ Service Manual Mechanical Part of SQR 472Engine
54
25
Intake/exhaust stud M8 16 10±1
Spread glue
26 Intake pipe nut M8 8 25±1.5
27 Ignition coil bracket assembly bolt M8 2 20±1.5
28 Front lifting lug bolt M8 2 20±1.5
29 Exhaust pipe nut M8 8 25±1.5
30 Exhaust pipe thermal shroud bolt M6 3 6±1
31
Bolt on crankshaft pulley & t
orsional damper
assembly
M12X1.25 1 100±5
32 Water pump pulley bolt M6 4 6±1
33 Water temperature sensor M12X1.5 1 15±1.5
34 Oil pressure switch 1 30±2
35 Spark plug M14X1.25 4 20±1
36 Fixing Bolt of spark plug cover board) M6 8 2.5±0.5
37 Bolt (intake pipe front bracket) M8 1 20±1.5
38 Bolt (intake pipe rear bracket) M8 4 20±1.5
39 Bolt (throttle cable) M6 2 6±1
40 Bolt (gas-oil spearator bracket) M6 2 6±1
41 Bolt (throttle valve casing) M6 4 6±1
42 Oxygen sensor M18X1.5 1 40±2
43 Bolt (intake temperature & pressure sensor) M4 1 3±1
44 Fixing bolt of fuel guide rail M6 2 7±1
45
Ignition coil bolt M6 3 5±1
