3. Brake Booster in the Retained Position
Closed vacuum
valve & control
valve
A is not connected
with B or C
Piston
Constant
pressure
chamber
Air valve
(closed)
Control valve
When in the retained position (brake force)
Valve control lever
Control valve spring
Vacuum valve (closed)
Stop
Variable pressure chamber
