Chery QQ Service Manual Chassis System
support with two bolts. When
applying brake, the fluid pressure
in rear caliper piston will
increase. The pressure acts on the
bottom of piston and cylinder and
transfers to lining in order to
push the surface of brake disc.
Caliper will slide on mounting
bolts to the center of vehicle.
with setting up pipe pressure, the
pressure on disc surface is higher
and higher to stop vehicle. When
loosing brake pedal, pipe
pressure will release. The
piston will be back slightly. The
movement of piston will
compensate the wear of lining.
Section three Shoe brake
1.Specifications
Spare part
Application Specifications
wheel cylinder piston diameter 19.05mm
Brake drum breadth 28mm
Brake drum diameter (new) 200mm
Finishing brake drum diameter 201mm
Maximum allow eccentricity 0.1mm
Brake lining diameter(rivet) 0.5mm
Tautness fasteners
Application Number value
Rear brake bottom plate bolt 50Nm
Wheel cylinder bolt 10Nm
Wheel cylinder linkage 16Nm
Exhaust valve 8Nm
ABS left wheel sensor bolt 6Nm
2. Service guide
1)Brake scrape gasket check
 Check brake lining when driving
every 1.5000km.
 Check lining when removing wheel
and tire.
 Remove the rubber cock on check
hole of lining.
 Check the thickness of lining.
 Whenever the wear of lining depth
exceeds 2mm, replace new lining. If
fixing lining with rivet, when wear
exceeds 0.5mm, replace new lining.
33
