Chery QQ - Removal of Window Winder; Removal of Front Door Weather Strip

Chery QQ Service Manual
panel.
（2） Fix the guide, block and 2 nuts after adjustment.
（3）Lift glass again and check to see if the installation is good or not.
Removal of window winder
（1）Take out the door inner panel.
（2）Loosen 2 set bolts of the window winder and
glass bracket
Hint: Stuff a piece of cloth inside the door inner
panel, so as not to cut the surface of the glass.
（3）Loosen 6 set bolts of the window winder.
The tighten torque: 5.5N·m (56kg-m, 491b-ft)
（4）Loosen the harness connector of the window winder; Take the window winder
assembly out.
Removal of front door weather strip
（1）Loosen screws and nuts.
（2）Take out the two sided adhesive tape from backward with scraper.
The installation sequence is in the reverse direction of the dismantle sequence.
As to dismantle of other door, you can see “dismantle of front door” for reference.
- 238 -
