Brake Booster Structure
Vacuum
Check valve
Constant-pressure chamber
Diaphragm
Power piston
Reaction disc
Valve body
Air
Variable-pressure chamber
Booster
housing
Push rod
Brake master
cylinder
Diaphragm spring
Booster housing
sealing member
Booster housing
sealing member
Air filter
Valve control
lever
