Chery QQ Service Manual Chassis System
Power steering system
Exterior identify
Power steering box
98
(1) Steering tie rod
socket unit
(2) Fixed ring
(3) Dust cap
(4) Lock
(5) Check nut
(6) Tie rod ripple cowl hoop
(7) Ripple cowl
(8) Steering box shell ripple cowl clamp
(9) Lock nut
(10) Tie rod in band ball
(11) Limiting stopper
(12) Circlet
(13) Facing ring
(14) Searing ring
(15) Bearing
(16) Nut
(17) Cover cap
(18) Lock nut
(19) Dust cap
(20) Circlet
(21) Tie rod end
(22) Check nut
(23) Tie rod ripple cowl hoop
(24) Ripple cowl
(25) Steering box
(26) Tie rod in band ball unit
(27) Limiting stopper
(28) Tube
(29) Oil pipe clip
(30) Hydraulic piping
(31) Hydraulic piping
(32) Trust sealing ring
Chery Automobile Co., Ltd
