Chery QQ - Removal of Headlamp; Removal of Horn; Removal of Tail Surface

Chery QQ Service Manual
（4）Loosen the harness connector of the mirror from the door inner panel; take out
the rearview mirror assembly.
Removal of headlamp
（1）Remove front bumper (see dismantlement of front bumper for reference)
（2）Loosen 3 set bolts, take out the head lamp.
Removal of horn
（1）Remove tire plate
（2）Loosen set bolts, take off the horn.
Removal of tail surface:
Loosen 3 set screws, take out tail wing
- 247 -
