Chery QQ Service Manual BCM Computer Control System
Ignition switch “ON”, power window switch
“DOWN”
Nonconducting
Ignition switch “ON”, power window switch
“UP”
Nonconducting
B9-Grounding
Ignition switch “ON”, power window switch
“DOWN”
Conducting
Ignition switch “ON”, antitheft switch “ON” Conducting
B10-Grounding
Ignition switch “ON, antitheft switch “OFF” Nonconducting
Open the boot lid Conducting
B11-Grounding
Shut the boot lid Nonconducting
Antitheft works Power supply
voltage
B13-Grounding
Antitheft fails Nonconducting
Open the door Conducting
B14-Grounding
Shut the door Nonconducting
B16-Grounding Normal Nonconducting
In case of difference with the above, BCM computer (antitheft computer) should be
maintained or replaced.
5). For power window control of antitheft computer, refer to “Power Window
Maintenance”.
6). For central door lock control of antitheft computer, refer to of “Central Door Lock
Maintenance”.
4. Division and match of QQ remote controls
QQ remote controls features two brands and three modules.
I) 9CG, two modules
1) Module 1
- 88 -
