Chery QQ Service Manual Chassis System
96
Steering column replace
Points of attention
Observe safety regulation during operating air
bag.
Remove procedure
1. Remove air bag unit and the steering
wheel with air bag.
2. Loosen the bolts.
3. Loosen the safety bolts.
Drill holes on safety bolts with electric
screwdriver to pull out the bolts.
4. Remove steering column.
Points of attention
Don’t turn ignition switch in LOCK position.
5. Remove up steering shaft and lower
steering guide bearing from pillar.
6. Remove lower steering guide bearing from
pillar.
7. Replace steering column.
Steps of installation
1. Insert steering column screw.
Points of attention
Note guide ears on shell.
2. Use 4 bolts to fix the shell and pillar.
Chery Automobile Co., Ltd
