Chery QQ - Overcharged Battery; Overhaul

Chery QQ Service Manual Charging System
than 20A, repair or replace the generator.
Overcharged battery
1. Please see section “Battery” for ensuring the status of the battery.
2. The excessively effusion of electrolyte is the obvious indication of being
overcharged. Then remove the generator to repair, and check the exciting coil winding
for ground connection or short circuit. If any trouble exists, replace the rotor and
check to ensure the output voltage is within the specified range.
. Overhaul Ⅲ
Removal and Installation
1. Remove negative cable from battery;
2. Disconnect the cable, which connects with terminal post B, and cable plugging
device;
3. Remove the bolt of engine cover (upside);
4. Remove the adjusting bolt of driving belt of generator;
- 25 -
