Chery QQ Service Manual Chassis System
Power steering pump replace
Disassembly procedure
1. Remove transmission belt and loosen adjust
bolts
Automobile Co., Ltd
102
Chery
2. Remove high-pressure hose and pipe from
steering pump. The fluid will flow into the
container. Please observe the safety regulation.
3. Remove the pump from front support.
Steps of installation
1. Put the pump on the support]
Fixture: 22-28Nm.
2. Install strengthen transmission belt.
3. Connect high-pressure hose and pipe on
steering pump again.
Power steering
Disassembly procedure
1. Loosen two connectors and remove out.
2. Remove tank from support.
Points of attention
Residual fluid will flow out into the container.
Steps of installation
1. Put the tank into support and screw bolts.
Connect two hoses and fix clamp.
2. Check if any leakage in system.
Power steering liqui
