Brake Booster not in Braking
Variable-pressure chamber
-chamber A
Relationship
between F
b
+ F
s
and F
a
F
b
=F
a
F
s
pushes the
piston to the right.
Brake master cylinder
Spring
Piston
Valve
Cylinder sleeve
Vacuum
To brake
wheel
cylinder
Constant-pressure chamber
-chamber B
