Chery QQ Service Manual Chassis System
Chery Automobile Co., Ltd
69
Chapter Three Suspension System
Section One Specifications
Tautness for Various Fasteners
Part No. Description Quantity Installation position
Torque
(N·m)
Q150B1010 Connecting bolts 2 Braking tube and clamp 13-17
Q151B1255 Bolts 3
Rear absorber and rear shaft M12×1.25,
rear shaft horizontal supporting rod and car
body
70-80
Q151B1285 Bolts 4 Rear towing arm and rear shaft 76-90
Q151B1290 Bolts 2 Lower swing arm and car body M12×1.25 76-90
Q151C1040 Bolts 2 Lower swing arm and knuckle M10×1.25 55-65
Q151C1080 Bolts 2 Lower swing arm and car body M10×1.25 60-70
Q151C1255 Bolts 4
Front sliding column and knuckle
M12×1.25
78-90
Q1421030
Hexagon head bolts and
spring washer assembly
2 Supporting frame and car body M10×1.25 35-45
Q1421035
Hexagon head bolts and
spring washer assembly
4
Supporting frame fixing stabilizing rod
M10×1.25
40-50
Q1440616 Screws 2 Supporting frame and car body 7-9
CQ32608 Screw nuts 6 Front sliding column and car body 22.5-27.5
CQ32610 Locking screw nuts 4
Suspended supporting frame and rear
transit supporting frame M10×1.25
55-65
CQ32612 Screw nuts 2
Stabilizing rod and lower swing arm
M12×1.25
60-70
Q1420820
Hexagon head bolts and
spring washer assembly
8 Brake and rear shaft 22-26
Q361B12 Screw nuts 10
Rear absor
b
er and car body; rear towing
arm and car body; rear shaft horizontal
supporting rod and car body; rear shaft
horizontal supporting rod and rear shaft
70-80
S11-330120
1
Screw nuts with washers 4 Rear towing arm and rear shaft 75-85
