Chery QQ - Disassembly and Installation of the Transaxle; Dismantle Transaxle

• Chery QQ Service Manual Transmission System
Section 3 Disassembly and installation of the transaxle
I Dismantle transaxle
Under the engine lid.
1． Disconnect the battery ground; remove the battery and the bracket.
2． Screw the clutch cable nut off, Remove the connector from the cable and
dismantle the cable from the bracket.
3． Disconnect the wiring harness and connector.
4． Remove the speedometer cable boot, and dismantle the speedometer cable.
5． Remove the fixing transaxle bolt.
6． Remove the 2 starter bolt and starter, meanwhile disconnect the starter cable.
7． Disconnect the vacuum hose from the map.
8． Hang engine and bracket chain，keep engine calm.
Caution:
Put gasket under the chain in order to prevent the damage of the vehicle surface.
On the Lift:
1． Use 10mm special tool and spanner to let out the transaxle oil.
