4. Brake Booster in the Released Position
Opened vacuum
valve & control
valve
A is connected
with B and C
Piston
Air valve
(closed)
Control valve
When in the released position (brake)
Valve control lever
Vacuum valve (opened)
Variable pressure chamber
Air valve return spring
Passage B
Passage A
