Chery QQ Service Manual
Remove rear window glass
1. Remove the following parts：
rear seat cushions
bolts on the lower end of rear seat belt
back of rear seat
speaker mesh guard
upper parking lamp
decorative board of glove compartment
assistant grasp
small rear seat illuminating light
inner roof lateral ornament
2. Detach roof lining
3. Disconnect rear window connector
Disconnect rear window connector
4. Remove lower inlaid strips
As showed in the drawing, cut off the double-side adhesive tapes
on the two ends of inlaid strip with scraping cutter
Note: Before using, scraping cutter point shall be bandaged with
adhesive tape
Prize out inlaid strips at six clamps and take the strips down
5. Remove rear window glass
Lead piano wire out between car body and glass
Bind up two wire ends with wood blocks or similar objects
Note：Do not let piano wire damage two stops
Remove the glass
6. Remove rear window inlaid strips
- 265 – Chery Automobile Co.,Ltd
