Rubber strip broken or damaged
because of being abrasion on the
edge
Rubber strip aging, surface torn
Replace
Replace
Water remains after wiping Paint, polishing agent and oil, etc left
on windshield
Wiping windshield with
clean rag dipped in
degreaser
Wiper blade works well on one
side, and emits crack on the
other side
Wiper rubber strip is deformed and
fails to work
Locating arm is distorted and wiper
blade sideling gets stuck on
windshield
Replace
Carefully make the arm
vertical
Part of surface can not be
wiped
Wiper rubber strip is dropped out the
groove wiper blade does not contact
windshield uniformly, spring or steel
strip get bent
Wiper arm contacts with windshield
under too great pressure
Insert the wiper rubber
strip in the groove
Replace
Lubricate wiper lever joint
and spring or replace the
arm
Ⅱ. Inspection and Repair of Horns
Only one horn is used in Chery S11, it is installed to the inside of front left bumper beam,
the current through the horn relay contacts is supplied by F4(10A)
Typical troubleshooting and solutions thereof are shown in the table
Table Typical troubleshooting and solutions of horn
Symptom
Causes Solution
Horn does not work Loose contact of the horn connector,
Fuse blowing out
Horn relay defective
Repair or replace
Replace
Replace
