Chery QQ Service Manual Chassis System
Section two Disc brake
1、Specifications
Unit Specifications
Application Dimension Specifications
Caliper piston diameter 48mm
Brake disc diameter 236mm
Brake disc reject depth comment 16mm
Brake disc minimum depth 17mm
Brake disc process depth 18mm
Brake disc depth new 20mm
Depth deviation 0.01mm
Maximal transverse hop 0.03mm
Maximal transverse hop assembly 0.1mm
Maximal scratch 0.4mm
Brake gasket depth 16mm
Minimum Brake gasket depth 7mm
Application Torque Specifications
Caliper bolt dowel pin 30N.m
Caliper bracket bolt 95N.m
Caliper linkage brake hosepipe 40N.m
Exhaust valve 8N.m
Front brake disc 6N.m
Cover plate 6N.m
Wheel bolt 110N.m
ABS front sensor bolt 10N.m
25
Chery Automobile Co., Ltd
