Chery QQ Service Manual Chassis System
2. Take off the outer cover of the
storage tank, draw the braking
liquid inside the tank by way of
a suction tube. The more
thoroughly the discharge of the
braking liquid, the better.
Points of attention:
Watch out the overflow of the braking
liquid.
Do not allow the braking liquid to
stain on the surface of the paint or
of the other parts and components so
as to avoid possible corrosion. If
the braking liquid stains on the
surface of the other parts and
components, an immediate cleaning
should be done to wipe them off.
3. Use a screwdriver to remove the
fixing screw between the liquid
storage tank and the master pump.
4. Separate the storage tank from
the master pump.
5. Take out the sealing rubber
sheath between the storage tank and
the master pump.
6. Check to see if there are any
cracks or deformations of the storage
tank.
7. Check the cover of the liquid
storage tank.
Make proper replacements if
there are any damages as follows.
 Cut openings
 Breaks and cracks
 Scrapes
 Deformations
8. Clean the liquid storage tank
with the compressed air not
containing lubricating agents.
Steps of installation
1. Apply adhesive agent for braking
master pumps (or clean braking liquid)
onto the new sealing sheath, and
install the rubber sheath into the
master pump, and then install the
liquid storage tank.
