Chery QQ Service Manual Chassis System
8. Resin the brake according to
following steps.
Right rear
Left rear
Right front
Left front
9. Install transparent plastic hose
to right rear valve.
10. Put other end of hose into the
container with clean fluid.
11. Slowly open the valve to flow out
fluid.
12. Close the valve when no bubbles
appear. fix the valve to 8 N.m.
Remove exhaust valve socket
14. If imperatively replace as
follows all rubber parts.
Brake hose assembly.
Master brake cylinder rubber
parts.
Brake pliers and brake drum seal.
15. Check the level of fluid and fill
fluid to correct level if necessary.
16、Install reservoir cover.
17. Drain out air in brake system.
Please refer to “ Draining out air
in hydraulic system”.
18. Lower vehicle
2)Hand work rinse
Points of attention：Use suitable
container and cloth to absorber brake
fluid and prevent the fluid to
contact any paint surface.
1. Clear fluid reservoir cover and
neighbor parts.
2. Remove the cover.
3. Drain out any fluid in the
reservoir.
4. Use clean OPEL DOT ４ brake fluid
to fill the reservoir to suitable
level.
5. Install the cover.
6. Lift and support the vehicle.
7. Rinse the brake system according
to following steps:
Right rear
Left rear
Right front
Left front
8. Install transparent plastic hose
to right rear exhaust valve.
9. Put the other end of hose into
container with clean fluid.
10. Slowly open the valve to flow out
fluid.
11. When clean fluid begins to flow
out, close the valve.
19
