Chery QQ Service Manual Chassis System
Chery Automobile Co., Ltd
71
II. Removal and installation of the front
balanced beam and the rubber sleeves
for the balanced beam
Removal
1、Loosen the two fastening screw nuts of the
supporting frame and car body. There is one
supporting frame on either side.
Attention: The fastening screws of the
supporting frames and guard plates should be
removed.
2、Loosen the two fastening screw nuts linking
the balanced beam supporting frame with the car
body.
3、 Remove the joining bolts of the balanced
beam and the lower swinging arm.
4、Remove the balanced beam and the rubber
sleeve.
