Chery QQ Service Manual
Only one small lamp light
1． Fuse
2． Harness
3． Bulb
Small lamp dose not work
(headlight is normal)
1． Small lamp fuse
2． Headlight switch
3． Harness
4． Small lamp bulb
Rear combination light dose not
light
1． Harness
2． Bulb
3． Headlight switch
Headlight beam height control
equipment dose not work
1． Headlight switch
2． Beam height control switch
3． Beam height control motor
4． Harness
Operate abnormally
1． Headlight switch
2． Beam height control switch
3． Beam height control motor
4． Fuse
5． Harness
Headlight beam
height control
equipment
（lamplight work
normally）
Operate abnormally（one side）
1． Beam height control motor
2． Fuse
3． Harness
Front foglight dose not light（small
lamp and headlight is normal）
1． Front foglight switch
2． Power supply fuse
3． Front foglight relay
4． Bulb
5． Harness
Front foglight dose not light
（headlight and small light don’t
light）
1． Headlight switch
2． Harness
Front foglight
equipment
Only one foglight dose not light
1． Bulb
2． Harness
Rear foglight dose not light（small
lamp and headlight is normal）
1． Foglight switch
2． Power supply fuse
3． Rear foglight relay
4． Bulb
5． Harness
Rear foglight dose not light
（headlight and small light don’t
light）
1． Headlight switch
2． Harness
Rear foglight
equipment
Rear foglight light, front foglight
dose not light
1． Foglight switch
2． Front foglight relay
3． Harness
4． Bulb
- 32 -
