Chery QQ Service Manual BCM Computer Control System
Central control lock “ON” Power supply
voltage
A12-Grounding
Central control lock “OFF” Conducting
Antitheft works Power supply voltage
A13-Grounding
Antitheft fails Nonconducting
Ignition switch “ON”, power window switch
“UP”
Conducting
A14-Grounding
Ignition switch “ON”, power window switch
“DOWN”
Power supply
voltage
Ignition switch “ON”, power window switch
“UP”
Power supply
voltage
A15-Grounding
Ignition switch “ON”, power window switch
“DOWN”
Conducting
Ignition switch “ON”, power window switch
“UP”
Conducting
A16-Grounding
Ignition switch “ON”, power window switch
“DOWN”
Power supply
voltage
Ignition switch “ON”, power window switch
“UP”
Power supply
voltage
A17-Grounding
Ignition switch “ON”, power window switch
“DOWN”
Conducting
Ignition switch “ON’, power window switch
“UP”
Conducting
A18-Grounding
Ignition switch “ON”, power window switch
“DOWN”
Power supply voltage
A19-Grounding
Normal Power supply
voltage
A21-Grounding
Normal Conducting
Ignition switch “ON”, power window switch
“UP”
Power supply
voltage
A22-Grounding
Ignition switch “ON”, power window switch
“Down”
Conducting
