follow the operating instruction of the device. The lost oil in compressor must be
measured and make-up the same amount of oil.
（4） remove the electric magnetic clutch lead from the wiring bundle of air
conditioner.
（5）remove the intaking hose and discharging hose from the compressor.
（6）take down the o-shape of seal ring from hose.
Note：cap the removed joints rapidly to avoid the system damp.
（7）lift the car and take the lower cover (right) of the engine down.
（8）slack the drive belt of the compressor, then remove the fixing bolts from
compressor.
（9）remove the compressor with the electric magnetic clutch assembly from the
engine st
and.
（10）discharge the compressor oil and measure the discharged amount of oil.
Note：
When the compressor is removed, care should be taken to avoid radiator rib of the
condensator to be damaged.
