Chery QQ Service Manual
8. Remove the reinforcement
rods of front bumper（left and
right）
Loosen four screws on upper side
and take down the reinforcement
rods
Remove inner bumper
① Take down the bundle of fog light
② Loosen four fixing nuts on left and
right
and take down inner bumper
Remove rear bumper
① Loosen two fixing screws on left and right
( in boot )
② Loosen two cross recess head screws in tail part
- 280 – Chery Automobile Co.,Ltd
