16-31
Cisco 10000 Series Router Quality of Service Configuration Guide
OL-7433-09
Chapter 16 Fragmenting and Interleaving Real-Time and Nonreal-Time Packets
Multilink PPP-Based Link Fragmentation and Interleaving
Step 4
Router(config-subif)# ppp chap hostname
hostname
(Optional) Identifies the hostname sent in the Challenge
Handshake Authentication Protocol (CHAP) challenge.
hostname is the name of the bundle group. This is the unique
identifier that identifies the bundle.
Note If you configure this command on the bundle and its
member links, specify the same identifier for both the
bundle and the member links.
Step 5
Router(config-subif)# no ip address
Removes any existing IP address from the main interface.
Step 6
Router(config-subif)# pvc [name] vpi/vci
Creates or modifies an ATM PVC. Enters ATM VC
configuration mode.
name is the name of the ATM PVC.
vpi/ is the virtual path identifier. If you do not specify a VPI
value and the slash character (/), the VPI value defaults to 0.
vci is the virtual channel identifier.
Step 7
Router(config-if-atm-vc)# vbr-nrt output-pcr
output-scr output-mbs
Configures the variable bit rate-nonreal time (VBR-nrt)
quality of service (QoS).
output-pcr is the output peak cell rate (PCR), in kbps.
output-scr is the sustainable cell rate (SCR), in kbps.
output-mbs is the output maximum burst cell size (MBS),
expressed in number of cells.
Step 8
Router(config-if-atm-vc)# encapsulation
{aal5mux ppp virtual-template number |
aal5ciscoppp virtual-template number |
aal5snap}
Configures the ATM adaptation layer (AAL) and
encapsulation type for an ATM virtual circuit (VC).
aal5mux ppp specifies the AAL and encapsulation type for
multiplex (MUX)-type VCs. The keyword ppp is Internet
Engineering Task Force (IETF)-compliant PPP over ATM. It
specifies the protocol type being used by the MUX
encapsulated VC. Use this protocol type for Multi-VC MLP
over ATM-based LFI to identify the virtual template. This
protocol is supported on ATM PVCs only.
aal5ciscoppp specifies the AAL and encapsulation type for
Cisco PPP over ATM. Supported on ATM PVCs only.
aal5snap specifies the AAL and encapsulation type that
supports Inverse ARP. Logical Link Control/Subnetwork
Access Protocol (LLC/SNAP) precedes the protocol
datagram.
virtual-template number is the number used to identify the
virtual template.
Command Purpose
